The 636 is a high-quality household hair dryer focused on constant temperature fast drying, stable performance and high durability. It supports universal 220-240V wide voltage with a rated power of 1000W, balancing powerful drying efficiency and gentle hair care. Suitable for daily home use, B&B and small commercial scenarios.
Adopting a dual-power structure with professional motor and reduction motor, paired with a CCS9 high-precision thermostat, this hair dryer accurately controls outlet temperature to prevent hair damage from overheating. It locks hair moisture while achieving fast drying. Multiple operation modes including cool wind and constant temperature hot wind meet diverse demands such as quick drying, hairstyle shaping and mild hair care.
Equipped with comprehensive safety configurations, including X2 safety capacitor, high-quality flame-retardant switch and VDE certified plug, together with standard compliant power cord for stable and safe electrical performance. The product has passed strict factory reliability tests, including high-voltage insulation test, drop test and power cord tension test with all indicators qualified. Professional temperature control block tests prove sensitive overheat protection and stable recovery performance, effectively avoiding overheating and dry-burning risks for higher safety.
With stable operating conditions, sufficient and balanced airflow speed and low noise in cool wind mode, the 636 provides a comfortable user experience. Standardized material configuration and strict quality control make it a cost-effective daily hair care appliance with excellent durability and compatibility.
1. Full Product Specifications
1.1 Electrical Specifications
|
Item |
Specification |
|
Model |
636 |
|
Voltage |
220–240 V AC |
|
Frequency |
50 / 60 Hz |
|
Rated Power |
1000 W |
1.2 BOM (Bill of Materials)
|
No. |
Part Name |
Specification |
|
1 |
Thermostat |
CCS9 130℃ |
|
2 |
Motor |
HL 365S 24V DC |
|
3 |
Reduction Motor |
FCD-20A130-03 24VDC |
|
4 |
Switch |
TS-14 7.5A 250V 15A 125V |
|
5 |
Power Cord |
H05VVF 2×0.75mm²×1.83m |
|
6 |
Plug |
VDE 16A 250V |
|
7 |
Safety Capacitor |
0.33uf X2 275V |
1.3 Performance Test (230V Standard Voltage)
Note: Temperature tested at Φ40mm and Φ50mm measuring points; noise data only recorded for cool wind gear (C); Test environment: ambient temperature 26℃, ambient noise 52dB, temperature test distance 15mm, noise test distance 150cm.
|
Gear |
Power (W) |
Speed (RPM) |
Air Volume (m/s) |
Temp Φ40℃ |
Temp Φ50℃ |
Noise (dB) |
|
C (Cool Wind) |
272 |
25250 |
4.2 |
38.7 |
38.5 |
76 |
|
2 (High Gear) |
987 |
25000 |
4.4 |
74.4 |
74.0 |
— |
|
1 (Low Gear) |
648 |
17200 |
3.0 |
73.2 |
74.4 |
— |
1.4 Thermostat Test
Note: 2 samples tested for air outlet blockage and air inlet blockage respectively; the thermostat features sensitive protection response and stable performance.
|
Test Item |
Air Outlet Block Sample 1 |
Air Outlet Block Sample 2 |
Air Inlet Block Sample 1 |
Air Inlet Block Sample 2 |
|
Thermostat Action Time |
4″18 |
4″02 |
3″98 |
4″09 |
|
Thermostat Recovery Time |
5′50″ |
5′17″ |
5′04″ |
5′14″ |
1.5 Reliability Test Results
|
Test Item |
Test Condition / Parameter |
Result |
|
High Voltage Test |
3750V 0.5MA 2S |
PASS |
|
Drop Test |
Bare unit dropped 3 times on cork board from 3 feet height |
PASS |
|
Power Cord Tension Test |
20 LBS tension lasts for 1 minute |
PASS |
|
Power Cord Length Inspection |
Exposed length 1.80m (including plug & sleeve) |
PASS |
1.6 Standard Test Conditions
